Max. PV Input Power	15000W
Rated AC Output Power	12000W

Voltage	230 VAC
Frequency Range	50Hz/60Hz (Auto Sensing
Selectable Voltage Range	170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)

Transfer Time,	10ms (For Personal Computers); 20ms (For Home Appliances)
AC Voltage Regulation ( Batt . Mode )	230VAC +/- 5%
Efficiency ( Peak )	93%
Waveform	Pure Sine Wave
Surge Power	22000VA
DC Voltage	N/A

Storage Temperature	-15 to 60 Degree Centigrade
Operating Temperature	-10 to 50 Degree Centigrade
Humidity	5% to 95% Relative Humidity (Non~Condensing)

Maximum Charge Current	150A
Maximum PV Input Current	27A X 2 (Max 40A)
Maximum PV Array Power	15000W (7500 X 2)
Maximum PV Array Open Circuit Voltage	500 VDC
Solar Charge Type	MPPT
MPPT Range @ Operating Voltage	90~450 VDC
Maximum Solar Charge Current	150A
Maximum AC Charge Current	150A

-	-

- Introducing 1st time in Pakistan, single phase Inverters support three phase when installed in parallel
- 100% Pure Sine wave Inverter
- Touch screen control module with various communications
- PV and utility power the load at the same time can be set
- Output power factor PF-1.0
- Energy generated record, load record history information and fault record
- Support Peak-Valley Charge
- Parallel operation up to 6 units
- Built-in two 15000W MPPTs, with wide input range: 90-450VDC
- Reserved communication parts (RS485, CAN-BUS, RS232)
- Upgraded 5th generation smart and intelligent solar inverter
- Zero transfer time
- Efficiently Work with & with out battery
- Optional Wi-Fi interface with Android & IOS
- Battery Equalization/Compatible with Li-ion, LifePo4 and etc )
- Conformal Coating to Prevent from Dust and Humidity
- Compatibility to utility main or generator units
- Replaceable fan design for ease of maintanance
- Support USB on-the-Go option
- Battery independent design
- Selectable high power charging current
- Over load and short circuit protection
- Dual outputs for smart load management
- PV input current increase 27*2A
- Status indication with RGB lights
- European design and engineered in Taiwan
- Built in zero export, 100% reverse grid feeding
